NEC NEAX Telephones

Please Note: The model number of your NEC NEAX telephone can usually be found on a label stuck on the bottom of the phone.

NEAX 2000 IPS & 2400 IPX PABX

SN 611 (2400SDS)

To fit a headset to this switchboard, unplug the handset and replace it with the appropriate amplifier. The handset cord then plugs into the amplifier.

Plantronics:
Any HW series headset and a M22 amplifier (position 5, transmit 9)

Plantronics Wireless CS540, CS510, CS520, CS530, CS Legend & Savi 710, 720, 730, 740:
Switch position 1, Transmit B, Receive 3, standard telephone cord wiring. This can also be used with the optional HL10 Handset Lifter.

Jabra/GN Netcom:
Any headset and a GN 8000 amplifier or GN 8210 digital amplifier.

ADD-COM:
Any headset and a Voyager amplifier.

HA 630Z & SN 626

To fit a headset to this switchboard, unplug the handset and replace it with the appropriate Two Pronged amplifier or amplifier and Two Pronged adaptor.

Plantronics:
Any HW series headset and a P10H amplifier.

Plantronics Wireless CS540, CS510, CS520, CS530, CS Legend & Savi 710, 720, 730, 740:
Switch position 1, Transmit B, Receive 3, standard telephone cord wiring. This can also be used with the optional HL10 Handset Lifter.

Jabra/GN Netcom:
Any headset and a GN 8000 amplifier or GN 8210 digital amplifier.

ADD-COM:
Any headset and a Two Prong amplifier.

Dterm 1

To fit a headset to these NEC NEAX phones, unplug the handset and replace it with the appropriate headset.

Plantronics:
Any HW series headset and a Polaris cable.

Plantronics Wireless CS540, CS510, CS520, CS530, CS Legend & Savi 710, 720, 730, 740:
Switch position 1, Transmit B, Receive 3, standard telephone cord wiring. This can also be used with the optional HL10 Handset Lifter.

Jabra/GN Netcom:
Any headset and a standard cord.

Sennheiser:
Any headset top and a CSTD01 cable. Also recommended is the headset/handset switchbox (UI 710)

ADD-COM:
Any headset and a BLUE Cord.

Dterm 11B & Dterm 111

To fit a headset to these NEC NEAX phones, unplug the handset and replace it with the appropriate amplifier. The handset cord then plugs into the amplifier.

Plantronics:
Any HW series headset and an M22 amplifier (Switch Setting 5, Transmit 10). Ensure that the handset volume is low - use the M22 volume control (this is to prevent squealing)

Plantronics Wireless CS540, CS510, CS520, CS530, CS Legend & Savi 710, 720, 730, 740:
Switch position 1, Transmit B, Receive 3, standard telephone cord wiring. This can also be used with the optional HL10 Handset Lifter.

Jabra/GN Netcom:
Any headset and a GN 8000 amplifier or GN 8210 digital amplifier.

ADD-COM:
Any headset and a Voyager amplifier.

Dterm Series e & Dterm Series i

To fit a headset to these NEC NEAX phones, unplug the handset and replace it with the appropriate headset.

Plantronics:
Any HW series headset and an A10 cable (a direct connect Polaris cord will provide a sufficient transmission level in a lot of circumstances). Please note: P series headsets have been recently discontinued.

Plantronics Wireless CS540, CS510, CS520, CS530, CS Legend & Savi 710, 720, 730, 740:
Switch position 1, Transmit B, Receive 3, standard telephone cord wiring. This can also be used with the optional HL10 Handset Lifter.

Jabra/GN Netcom:
Any headset and a standard cord.

Sennheiser:
Any headset top and a CSTD01 cable. Also recommended is the headset/handset switchbox (UI 710)

ADD-COM:
Any headset and a BLUE Cord.

DT330 Series: DTL-24D-1A

To fit a headset to these NEC NEAX phones, simply plug into the dedicated headset jack.

Plantronics:
Any HW series headset and an A10 cable.

Plantronics Wireless CS540, CS510, CS520, CS530, CS Legend & Savi 710, 720, 730, 740:
Switch position 1, Transmit B, Receive 3, standard telephone cord wiring. This can also be used with the optional HL10 Handset Lifter.

Jabra/GN Netcom:
Any headset and a standard cord.

Sennheiser:
Any headset top and a CSTD01 cable. Also recommended is the headset/handset switchbox (UI 710)

ADD-COM:
Any headset and a BLUE Cord.

NEAX Univerge PABX

Telephones DT300 Series (DT310, DT330)and DT700 Series (DT710, DT730 & DT750

To fit a headset to these NEC NEAX phones, simply plug into the dedicated headset jack.

Please Note: You must program one of the Programmable Keys on your phone to act as a headset key.

To do this, leave the handset on your phone and:

1. Find a suitable FREE key by pressing each in turn until your display shows "not defined"
2. Press "Speaker" button
3. Press 751
4. Press the key chosen in step 1 above
5. Press 05 to give it HEADSET status

To make calls using your headset, simply press this HEADSET button. To hang up calls, press it again.

Plantronics:
Any HW series headset and an A10 amplified cable.

Plantronics CS540, CS510, CS520, CS530, CS Legend & Savi 710, 720, 730, 740:
Switch position 1, Transmit B, Receive 3, standard telephone cord wiring. This can also be used with the optional HL10 Handset Lifter.

Jabra/GN Netcom:
Any headset and a standard cord.

Sennheiser:
Any headset top and a CSTD01 cable. Also recommended is the headset/handset switchbox (UI 710)

ADD-COM:
Any headset and a BLUE Cord.

NEAX 7400 ICS (110 / 120 / 140 / 160 / 180) PABX

HA 630Z, SN 626 & SN 708

To fit a headset to this NEC NEAX switchboard, unplug the handset and replace it with the appropriate amplifier. The handset cord then plugs into the amplifier.

Plantronics:
Any HW series headset and a M22 amplifier (position 1, transmit 2). No batteries required. Ensure that the handset volume is low - use the M22 volume control (this is to prevent squealing)

Plantronics Wireless CS540, CS510, CS520, CS530, CS Legend & Savi 710, 720, 730, 740:
Switch position 1, Transmit B, Receive 3, standard telephone cord wiring. This can also be used with the optional HL10 Handset Lifter.

Jabra/GN Netcom:
Any headset and a GN 8000 amplifier or GN 8210 digital amplifier. Requires a two prong adaptor.

ADD-COM:
Any headset and a Voyager amplifier.

SN 694

To fit a headset to this NEC NEAX switchboard, unplug the handset and replace it with the appropriate amplifier. If the amplifier is not Two Pronged then you must use a Two Prong adaptor.

Plantronics:
Any HW series headset and a M22 amplifier (position 1, transmit 2). No batteries required. Ensure that the handset volume is low - use the M22 volume control (this is to prevent squealing). Requires a K plug.

Plantronics Wireless CS540, CS510, CS520, CS530, CS Legend & Savi 710, 720, 730, 740:
Switch position 1, Transmit B, Receive 3, standard telephone cord wiring. This can also be used with the optional HL10 Handset Lifter.

Jabra/GN Netcom:
Any headset and a GN 8000 amplifier or GN 8210 digital amplifier. Requires a two prong adaptor.

ADD-COM:
Any headset and a Voyager amplifier. Requires a K plug.

Dterm 6D, Dterm 16D & Dterm V

To fit a headset to these NEC NEAX phones, unplug the handset and replace it with the appropriate amplifier. The handset cord then plugs into the amplifier.

Plantronics:
Any HW series headset and an M22 amplifier (Switch Setting 5, Transmit 10). Ensure that the handset volume is low - use the M22 volume control (this is to prevent squealing)

Plantronics Wireless CS540, CS510, CS520, CS530, CS Legend & Savi 710, 720, 730, 740:
Switch position 1, Transmit B, Receive 3, standard telephone cord wiring. This can also be used with the optional HL10 Handset Lifter.

Jabra/GN Netcom:
Any headset and a GN 8000 amplifier or GN 8210 digital amplifier.

ADD-COM:
Any headset and a Voyager amplifier.

NEAX 7400 IMX PABX

SN716, Dterm 75, DPT-8-1A, DPT-16D-1A & DPT-31D-1A

To fit a headset to these consoles/switchboards, unplug the handset and replace it with the appropriate headset.

Plantronics:
Any HW series headset and an A10 cable. Please note: P series headsets have been recently discontinued.

Plantronics Wireless CS540, CS510, CS520, CS530, CS Legend & Savi 710, 720, 730, 740:
Switch position 1, Transmit B, Receive 3, standard telephone cord wiring. This can also be used with the optional HL10 Handset Lifter.

Jabra/GN Netcom:
Any headset and a standard cord.

Sennheiser:
Any headset top and a CSTD01 cable. Also recommended is the headset/handset switchbox (UI 710)

ADD-COM:
Any headset and a BLUE Cord.

Dterm 8DC, 16DS, 16DD & 24DS (also known as ETJ Series)

To fit a headset to these phones, unplug the handset and replace it with the appropriate amplifier or wireless headset base. The handset cord then plugs into the amplifier/base.

Plantronics corded:
Any HW series headset and an M22 amplifier (Switch Setting 5, Transmit 8) OR any P series headset and an NEC ADA-J headset adaptor.

Plantronics CS540, CS510, CS520, CS530, CS Legend & Savi 710, 720, 730, 740:

CS 500 or Savi Series:
Switch position A, Transmit 3, Receive 3.
For remote answer/release use the Plantronics HL10 handset lifter.

GN Netcom:
Any headset and a GN 8000 amplifier or GN 8210 digital amplifier.

ADD-COM:
Any headset and a Voyager amplifier OR any headset with an NEC ADA-J headset adaptor.
